Automatic 10g-1500g carbon steel economical multihead weigher for weighing small weight granules


Carbon steel economical multihead weigher is suitable for weighing small weight granules such as chinese medicine tablets, tea, coffee beans, chocolate beans, currants and other snack food, hardware, plastic particles and other particulate materials quantitative weighing.

application of multihead weigher


1. Special load cell with high precision and high standard.

2. Program recovery function can reduce operation failures and support multi-segment weight calibration.

3. Linear amplitude can be adjusted independently.

4. Many languages available for global markets.

5. 100 programs capacity can meet various weighing requirements and user-friendly help menu contributes to easy operation.

Mechanical character

1. New machine design —Ⅱseries, elegant appearance.

2. Easy moveable design for in-feed funnel and discharge funnel, which is more convenient to clean it.

3. Mold making process and uniform design standards contribute to better interchangeability for spare parts.

4. Variously optional accessories can meet various weighing requirements.

5. Adopt food grade plastic hoppers, which are easier for cleaning.

Technical specification

Name1st G 10heads II Series Carbon Steel Economical Multihead weigher1st G 14heads II Serie Carbon Steel Economical Multihead weigher
Identify CodeA10-1-18TSA14-1-18TS
Weighing Range10-1000g10-1500g
Max Speed65P/M120P/M
Hopper Volume2.0L(plastic)
Control Panel7”Touch Screen
OptionsTiming Hopper/Printer/Reject Device
Driving SystemStep Motor
Power Requirement220V/1000W/ 50/60Hz/8A220V/1200W/50/60Hz/10A
Packing Dimension(mm)1770(L)x1100(W)x1330(H)1770(L)x1100(W)x1330(H)
Gross Weight370kg470kg
