Application

Super mini Multihead Weigher Machine is suitable for weighing small weight granules such as seeds, tea, coffee beans etc.

High Speed Granular Multihead Weigher Machine for Seed, Tea, Coffee

Features

1. Adopt high accurate loadcell of famous brand, resolution is improved up to 2 decimal.

2. Program recovery function can reduce operation failures and support multi-segment weight calibration.

3. No products auto pause function can improve weighing stability and accuracy.

4. Linear amplitude can be adjusted independently.

5. Many languages available for global markets.

6. 100 programs capacity can meet various weighing requirements and user-friendly help menu contributes to easy operation.


Mechanical Character

1. 0.3L hopper, low vibrating design, good performance.

2. Use weighing type for material detection to make accurate control of feeding time & material thickness and ensure weighing accuracy.

3. V feeder pan especially designed for small target weight to ensure even feeding and weighing accuracy.

4. Integral machine frame with middle standing enhances the strength of the machine, making the time for stabilizing hoppers much shorter.

5. Arc-shaped machine body with large R treatment improves the stability and appearance.

6. New double parallel linear vibrator contributes to smaller vibration, side-driven actuator makes the reading more accurate and the weighing accuracy higher.

Technical Specification

ModelJW-A10JW-A14
Identify CodeAS10-1-2AS14-1-2
Weighing Range1-60g1-60g
AccuracyX(0.5)X(0.5)
Max Speed60P/M120P/M
Hopper Volume0.3L
Control Panel7''Touch Screen
OptionsDimple Plate/Timing Hopper/Printer/Reject Device
Driving SystemStep Motor
Power Requirement220V/900W/50/60Hz/8A220V/1100W/50/60Hz/10A
Packing Dimension(mm)1190(L)x970(W)x950(H)1190(L)x970(W)x950(H)
Gross Weight180kg220kg


Product Details
